A.O. Smith ATM-160X3 Tankless Water Heater 10.5 GPM, 160,000 BTU

Endless Hot Water
Space Saving Design
Energy Efficient
Consistent Flow
Price
$3,399 $2,599
Save  $800
Monthly Payment Plan
$28.95 /month
Financing help available
Delivery & installation included with both options.
✓ Secure checkout ✓ Installation included ✓ Warranty protection
Installation Within 2 Days GTA & Nearby
Attribute Details
Make A. O. Smith
Series Adapt® SC
Model ATM-160X3-N
Product Type Standard Condensing Tankless Water Heater
Installation Location Indoor or Outdoor with Appropriate Outdoor Vent-Cap Kit
Mounting Type Wall Mounted
Fuel Type Natural Gas
Maximum Heating Input 160,000 BTU/h
Minimum Heating Input 10,000 BTU/h
Maximum Flow Rate Up to 10.5 GPM
Flow Activation Rate 0.4 GPM
Continuous-Fire Flow Rate 0.26 GPM
Uniform Energy Factor 0.95 UEF
ENERGY STAR® Certified Yes
Emissions Rating Ultra-Low NOx
Scale Prevention Integrated X3™ Scale Prevention Technology
Primary Heat Exchanger Commercial-Grade Copper
Secondary Heat Exchanger Stainless Steel
Recirculation Pump Not Integrated; Compatible with Approved External Recirculation Systems
Temperature Range 100°F–140°F (38°C–60°C)
Default Temperature Setting 120°F (49°C)
Temperature Control Built-In Digital Control Display
Ignition System Electronic Ignition
Water Pressure Range 15–150 PSI
Recommended Water Pressure 40 PSI for Maximum Flow
Water Connections 3/4-Inch NPT Hot- and Cold-Water Connections
Gas Connection 3/4-Inch NPT
Power Supply 120V, 50/60Hz, Less Than 5A
Sound Level Approximately 51 dB Under Test Conditions
Venting Type Power Direct Vent
Approved Venting Materials PVC, CPVC or Polypropylene
Maximum Vent Length 2-Inch up to 50 Equivalent Feet; 3-Inch up to 150 Equivalent Feet
Outdoor Installation Requires the Appropriate A. O. Smith Outdoor Vent-Cap Kit
Freeze Protection Internal Heater Protection to -5°F (-21°C); X3 Cartridge Requires a Separate Freeze-Protection Kit
Elevation Certification Sea Level to 7,800 Feet
Cascade Capability Up to 12 Compatible Units
Dimensions (H × W × D) 40.4 × 17.1 × 11.9 Inches
Unit Weight 83 lb
Application Residential Domestic Hot Water; Commercial Applications Where Properly Sized and Approved
Suitable For Professionally Sized Homes with Moderate to Higher Hot-Water Requirements
Residential Warranty 15-Year Limited Heat Exchanger Warranty and 5-Year Limited Parts Warranty
Commercial Warranty 1-Year Limited Heat Exchanger and Parts Warranty

The A. O. Smith ATM-160X3-N Adapt® SC Tankless Water Heater is a high-efficiency natural-gas water heater designed to provide continuous, on-demand hot water for residential applications. With up to 160,000 BTU/h of heating input and a maximum rated flow of 10.5 GPM, it delivers dependable hot-water performance for professionally sized homes.

Unlike a conventional storage-tank water heater, the ATM-160X3-N heats water only when a hot-water fixture is being used. Its modulating operation adjusts heating output according to demand, helping reduce standby energy loss while supporting efficient natural-gas consumption.

With a 0.95 Uniform Energy Factor and ENERGY STAR® certification, this condensing tankless water heater captures additional heat from combustion exhaust before it leaves the system. This helps improve energy utilization while providing consistent hot-water performance.

Integrated X3™ Scale Prevention Technology helps prevent minerals from adhering to the heat exchanger. This technology helps the system maintain like-new performance for longer and eliminates the need for annual descaling under normal operating conditions, making it especially valuable for homes in hard-water areas.

The unit combines a commercial-grade copper primary heat exchanger with a stainless-steel secondary heat exchanger. This dual heat-exchanger construction supports efficient heat transfer, corrosion resistance and dependable long-term operation.

The compact wall-mounted cabinet measures approximately 40.4 inches high, 17.1 inches wide and 11.9 inches deep. It can be installed indoors or outdoors with the appropriate A. O. Smith outdoor vent-cap kit, providing flexible placement for replacement and new-construction applications.

A built-in digital control display allows convenient temperature adjustment from 100°F to 140°F, with a factory default setting of 120°F. The display also provides access to operating status, settings and system error information.


Key Features

Up to 160,000 BTU/h Heating Input
Provides responsive heating capacity for professionally sized residential hot-water applications.

Maximum Flow Rate up to 10.5 GPM
Supports high-flow on-demand hot-water delivery. Actual flow depends on incoming-water temperature, required temperature rise, water pressure and simultaneous household demand.

Continuous On-Demand Hot Water
Heats water when required and provides a continuous supply when properly sized for the household’s hot-water requirements.

0.95 UEF Efficiency
Uses condensing technology to capture additional exhaust heat and support efficient natural-gas operation.

ENERGY STAR® Certified
Meets ENERGY STAR® requirements for qualifying high-efficiency gas water heaters.

Integrated X3™ Scale Prevention
Helps prevent mineral buildup, maintain heat-exchanger performance and eliminate annual descaling under normal operating conditions.

Dual Heat-Exchanger Construction
Combines a commercial-grade copper primary heat exchanger with a corrosion-resistant stainless-steel secondary heat exchanger.

Built-In Digital Control
Provides convenient temperature adjustment, system-status information, operating settings and error-code display.

Adjustable Water Temperature
Supports water-temperature settings from 100°F to 140°F, with a factory default setting of 120°F.

Low-Flow Activation
Activates at approximately 0.4 GPM and supports continuous firing at approximately 0.26 GPM.

Ultra-Low NOx Operation
Reduces nitrogen-oxide emissions while maintaining dependable natural-gas performance.

Flexible Condensing Venting
Supports approved PVC, CPVC and polypropylene venting with two-inch or three-inch configurations, subject to manufacturer instructions and applicable codes.

Indoor or Outdoor Installation
Supports indoor installation or outdoor mounting with the appropriate A. O. Smith outdoor vent-cap kit.

Compact Wall-Mounted Design
Measures approximately 40.4 × 17.1 × 11.9 inches and weighs approximately 83 lb, helping preserve valuable floor space.

Cascade Capability
Allows up to 12 compatible units to operate together in applications requiring greater combined hot-water capacity.

Residential Warranty Protection
Includes a 15-year limited heat-exchanger warranty and a five-year limited parts warranty for qualifying residential applications. Manufacturer terms and conditions apply.


Suitable Applications

  • Professionally sized single-family homes
  • Homes requiring continuous on-demand hot water
  • Properties with limited mechanical-room floor space
  • Hard-water areas that benefit from X3™ Scale Prevention Technology
  • Indoor installations or suitable outdoor installations with the required vent-cap kit
  • Cascade systems requiring greater combined hot-water capacity

Actual hot-water output and the number of fixtures that can operate simultaneously depend on incoming-water temperature, required temperature rise, water pressure and total demand. Professional sizing is recommended before purchase and installation.


Why Buy the A. O. Smith ATM-160X3-N Tankless Water Heater?

The A. O. Smith ATM-160X3-N is an excellent option for homeowners seeking efficient, continuous hot water in a compact wall-mounted system. Its 160,000 BTU/h maximum input, 10.5 GPM maximum rating, 0.95 UEF and ENERGY STAR® certification provide a strong balance of hot-water performance and energy efficiency.

Integrated X3™ Scale Prevention Technology, dual heat exchangers, digital temperature control and flexible indoor or outdoor installation further improve durability, convenience and installation versatility. Contact Jimmy HVAC for a free quote and professional assessment to confirm whether the ATM-160X3-N is the correct capacity for your home.
