YORK 60000 BTU 96% AFUE Two-Stage Gas Furnace – TM9Y060B12MP11

Upgrade your home heating with the YORK TM9Y060B12MP11, a high-efficiency 60,000 BTU two-stage gas furnace designed to provide dependable heating, efficient operation and consistent indoor comfort.

With up to 96% AFUE, a two-stage gas valve, standard ECM motor and flexible multi-position installation, the TM9Y series is designed for a wide range of residential HVAC applications.

This model provides 58,000 BTU high-fire output and 37,000 BTU low-fire output, with a rated airflow of 1,200 CFM. It is factory configured for natural gas and can be converted for LP/propane operation using the appropriate conversion kit.

Key Features

96% AFUE High-Efficiency Heating
The YORK TM9Y060B12MP11 is rated at up to 96% AFUE, helping convert more of the fuel’s energy into useful heat for your home.

Two-Stage Heating
The two-stage gas valve allows the furnace to operate at different heating levels, supporting more consistent heating and improved indoor comfort during typical heating conditions.

60,000 BTU Heating Input
This model provides a 60,000 BTU high-fire input with a lower 39,000 BTU low-fire input.

Multi-Position Installation
The TM9Y series supports upflow, horizontal left/right and downflow installation configurations with the required conversion procedures.

Standard ECM Motor
The furnace uses a standard ECM constant-torque motor designed to provide controlled airflow and efficient HVAC system operation.

Natural Gas / LP Convertible
The furnace is designed for natural gas operation and can be converted for LP/propane gas using the appropriate YORK conversion kit.

Compact Cabinet Design
The TM9Y cabinet is designed for residential installation flexibility while maintaining a compact footprint.

ENERGY STAR Certified
The TM9Y series is available as an ENERGY STAR certified high-efficiency furnace. Verify the certification listing for the exact model when required.

Technical Specifications

Professional Installation Included

Your purchase includes professional furnace installation by qualified HVAC technicians. Installation scope may vary depending on the existing HVAC system, venting, gas connection, electrical configuration, ductwork and local requirements.

Warranty Protection

10-Year Limited Parts Warranty*
The YORK TM9Y series is covered by YORK’s applicable limited parts warranty, subject to current warranty terms and registration requirements.

3-Year Labour Warranty
Jimmy HVAC includes a 3-year labour warranty with this product under the applicable Jimmy HVAC warranty terms.

*Manufacturer warranty coverage is subject to YORK’s current warranty terms, registration requirements and applicable conditions.

Why Buy the YORK TM9Y060B12MP11?

• Up to 96% AFUE efficiency
• Two-stage heating for controlled operation
• 60,000 BTU heating input
• 58,000 BTU high-fire output
• 37,000 BTU low-fire output
• 1,200 CFM airflow
• Standard ECM constant-torque motor
• Multi-position installation flexibility
• Natural gas with LP/propane conversion capability
• ENERGY STAR certified
• Professional installation included
• 10-year limited parts warranty*
• 3-year labour warranty

What’s Included

• YORK TM9Y060B12MP11 gas furnace
• Professional installation
• Standard installation materials as applicable
• 3-year labour warranty
• Manufacturer’s applicable limited parts warranty

Frequently Asked Questions

What size is the YORK TM9Y060B12MP11?
The TM9Y060B12MP11 has a 60,000 BTU/hr high-fire input and is rated at approximately 3 Ton.

Is the YORK TM9Y060B12MP11 two-stage?
Yes. This model uses a two-stage gas valve and two-stage heating operation.

Is this furnace 96% AFUE?
Yes. The TM9Y series is designed as a high-efficiency furnace with up to 96% AFUE.

Can this YORK furnace use LP gas?
Yes. The TM9Y series is convertible for LP/propane operation using the appropriate conversion kit.

Can this furnace be installed horizontally?
Yes. The TM9Y series supports upflow, horizontal left/right and downflow configurations with the required installation procedures.

Does installation come included?
Yes. Professional installation is included with the Jimmy HVAC purchase, subject to the applicable installation scope and site requirements.

What is the airflow of this model?
The TM9Y060B12MP11 is rated for 1,200 CFM nominal airflow.
