Kepler LUXE 5 Ton Heat Pump with Uncased Coil – 60K BTU

Durable Design
Fast & Reliable
Quiet Operation
Energy-efficient
Price
$8,756 $7,005
Save  $1,751
Monthly Payment Plan
$77.95 /month
Financing help available
Current offers available while stock lasts
✓ Secure checkout ✓ Installation included ✓ Warranty protection
Installation Within 2 Days GTA & Nearby

Kepler LUXE 5 Ton Heat Pump with Uncased Coil is a central ducted heating and cooling system featuring inverter technology, a side-discharge outdoor unit and a 60,000 BTU/h nominal capacity class.

Attribute Details
Brand Kepler
Series LUXE
Product Type Central Ducted Heat Pump System
Nominal Capacity Class 5 Ton / 60,000 BTU/h
Outdoor Unit Model AZPN/60WD
Indoor Coil Model AZPN/D60WAC-UC
Indoor Coil Type Uncased Evaporator Coil
Compressor Technology Inverter-Driven
Outdoor Unit Design Side Discharge
System Type Central Ducted Air-Source Heat Pump
Outdoor Power Supply 208/230V, Single Phase, 60Hz
Refrigerant R-410A

Warranty Details

Warranty Type Coverage
Product Warranty 10 Years
Labour Warranty 1 Year

Kepler LUXE 5 Ton Heat Pump with Uncased Coil

The Kepler LUXE 5 Ton Heat Pump is a central heating and cooling system designed for year-round residential comfort. Featuring inverter technology and a compact side-discharge outdoor condenser, it provides variable-capacity operation for compatible central HVAC applications.

This product configuration pairs the Kepler AZPN/60WD outdoor heat pump with the AZPN/D60WAC-UC uncased evaporator coil. The uncased coil is designed for compatible HVAC installations using a suitable indoor cabinet or air-handler arrangement.

Key Features

  • 5-ton nominal heat pump class
  • 60,000 BTU class system
  • Inverter-driven compressor technology
  • Compact side-discharge outdoor condenser
  • Uncased evaporator coil configuration
  • 14.5 SEER2 and 7.1 HSPF2 Region V ratings listed for the manufacturer’s cased-coil combination
  • 208/230V, single-phase, 60Hz outdoor power supply
  • R410A refrigerant

Outdoor Unit Specifications

Brand Kepler
Series LUXE
Nominal size 5 Ton
Outdoor model AZPN/60WD
Indoor uncased coil AZPN/D60WAC-UC
Published cased-coil AHRI reference 213062286
Cooling capacity 53,000 BTU/h rated
Cooling capacity range 13,400–54,000 BTU/h
Cooling input 6,162 W listed
Cooling current 26.80 A listed
SEER2 14.5 for cased-coil combination
EER2 8.6 for cased-coil combination
Heating capacity 55,000 BTU/h rated
Heating capacity range 10,800–60,000 BTU/h
Heating input 5,373 W listed
COP 3.0 listed
HSPF4 8.6 for cased-coil combination
HSPF2, Region V 7.1 for cased-coil combination
Outdoor power supply 208/230V, 1 phase, 60Hz
Minimum circuit ampacity 40 A
Outdoor dimensions (W × D × H) 37.48 × 16.34 × 52.48 in
Outdoor net weight 239.86 lb
Outdoor gross weight 271.61 lb
Outdoor noise level 62 dB(A)
Refrigerant R410A

Warranty

Product warranty 10 years
Labour warranty 1 year
